TECHNO 45 Solid-Fuel Steel Boiler

Info

Gallery

Download

Documents

Packaging

This boiler is designed to burn different solid burning materials efficiently. The automatic heat exchanger cleaning system is the most noticeable feature of this boiler. Thanks to its maximum heat transfer obtaining construction and chrome turbulators in the heat exchanger section, provides maximum fuel savings. It has 45KW heating capacity and 90 Liter water capacity , a maximum working pressure of 3 bar and maximum boiler outlet water temperature of 90℃.

Product Information:

No. 81-2710
Heating Capacity  52 KW
Heating Capacity 45000 (Kcal/Kg)
Water Capacity 120 Liter
Weight 335 Kg
Working Pressure 3 Bar
Test Pressure 4.3 Bar
Max Boiler Outlet Water Temperature 85 ℃
Bunker Fuel Capacity 125 Kg
Hopper Capacity 90 Liter
Chimney Dimension 140 mm
